Product Overview
Compact all-in-one device with central control screen for freight and logistics monitoring. Supports 4-channel AHD video input, AI blind spot warnings, sentry mode, fuel theft prevention alerts, AI voice recognition, and 4G remote monitoring.
Key Features
- Multi-Channel Video: 4-channel AHD video input, simultaneous recording in H.264 format (saved separately per channel)
- AI Detection & Alerts: Built-in AI algorithms for blind spot warnings, fuel theft prevention, and voice recognition
- Sentry Mode: Enhanced security monitoring mode
- Remote Monitoring: 4G connectivity enables remote live view, playback, track viewing, electronic fence, fleet management
- Flexible Display: 10.1-inch IPS touchscreen; default 4-screen display, supports switching to single-channel full screen
- Stable Power: 12V-36V wide voltage input, compliant with automotive-grade surge, overload, over-voltage, under-voltage, and short-circuit protection circuits
| Product Form | 4-channel monitoring all-in-one central control screen |
| Display | 10.1-inch IPS (1024x600), 2.5D Touchscreen |
| Processor/Mem | Yizhi SA230 / DDR3L 256MB |
| Video Input | 4-channel AHD |
| Recording | H.264, 4-CH separate storage, Cyclic, Time-lapse |
| External Cameras | 4x 1/3 CMOS 150° Ultra-wide Angle |
| Storage | TF Card (Class10, Max 256GB) |
| Power Supply | 12V-36V (Typ. 10W consumption) |
| Network/Pos | 4G Remote Monitoring / GPS |
| Working Temp | -20℃ ~ +70℃ |
In The Box
1x D901 Main Unit, Cable Harness, Installation Kit
