Product Overview
Designed for non-standardized industries (ride-hailing, logistics, construction vehicles), supporting 4-channel HD video, multi-mode positioning, and AI safety systems (DMS/ADAS/BSD). Compliant with Chinese Ministry standards for versatile applications.
Key Features
- HD Video: 4x AHD 1080P/720P input, H.265/H.264 encoding, CVBS output
- AI Safety DMS: Driver face recognition, fatigue/distraction/smoking/obstruction detection (requires DMS camera)
- AI Safety ADAS: Forward collision, lane departure, pedestrian alerts (requires front camera)
- AI Safety BSD: Left/right blind spot alerts (requires BSD camera)
- Precision Positioning: GPS/BeiDou/Galileo multi-mode (optional RTK with 0.02m accuracy)
- Global Connectivity: 4G multi-network, optional WiFi/Bluetooth/Ethernet
- Flexible Control: 4x input/1x output IO, 1x RS485 + 1x RS232, external sensor support
- Stable Power: 9-36V wide voltage input, <3W power consumption
- Certifications: Compliant with JT/T 808/794/1076/1078/905 standards
| Operating System | Linux 4.3 |
| Processor | Dual-core ARM CortexA7, 1.3GHz, 0.5TOPS Computing Power |
| Video Input | 4 Channels AHD 1080P/720P |
| Encoding | H.265 / H.264 |
| Storage | Single/Dual TF Card (Max 512GB) |
| Power Supply | 9~36V Wide Voltage (<3W Consumption) |
| Interfaces | 1x RS485, 1x RS232, 4x In / 1x Out IO, CVBS Out |
| Sensor | 3-axis Gyroscope |
| Working Temp | -20℃~70℃ |
| Dimensions | 90mm x 90mm x 30mm |
| Weight | 295g (Main Unit) |
In The Box
1x D604 MDVR, 1x Power Harness, 1x I/O Cable, 1x GPS Antenna, 1x 4G Antenna
