Product Overview
Compact ultra-thin IP65 waterproof design, integrating high-sensitivity GPS/BeiDou/LBS positioning for real-time tracking. Features ACC detection, intelligent alarms (fence/speed/power), and a robust watchdog system for system stability. Ideal for car rental, logistics, private cars, and electric scooters.
Key Features
- Compact & Waterproof: 14mm thick ultra-thin design with IP65 rating
- Precision Positioning: GPS/BeiDou/LBS triple-mode tracking
- Intelligent Alerts: Fence entry/exit, speeding, power outage, and vibration alarms
- Robust Stability: Built-in watchdog functionality with auto-recovery from crashes
- Versatile Application: Suitable for 9-90V vehicles including logistics trucks, rental cars, and scooters
| Network | GSM/GPRS (850/900/1800/1900MHz) |
| Working Voltage | 9-90V DC |
| Working Current | 12V/30mA (Avg) |
| Positioning | GPS/BeiDou (<5m error) |
| Start Time | Cold 32s / Hot 1s |
| Sensitivity | Tracking -162dBm / Capture -148dBm |
| Battery | Built-in 100mAh/3.7V Li-polymer |
| Dimensions | 78mm x 26mm x 14mm |
| Weight | 26.5g |
In The Box
1x C08W Unit, 1x Power Cable, 1x User Manual, 1x Relay (Optional)
