Product Overview
Designed for asset risk control, the C08L integrates GPS/BeiDou/GLONASS triple-mode positioning with low power consumption, real-time monitoring, and remote control capabilities. It is the ideal solution for reliable cargo tracking and vehicle security, featuring a robust design with anti-removal protection and OTA remote management.
Key Features
- Precision Positioning: Triple-mode (GPS/BeiDou/GLONASS) with <10m error and AGPS support
- Low Power Design: Auto-sleep mode with vibration-triggered activation
- Advanced Security: Remote fuel/power cutoff, anti-tamper alerts, and anti-fake base station detection
- Robust Reliability: Anti-removal SIM slot, dual hardware/software protection, defect rate <3‰
- Customization Ready: Supports JT808 protocol and private customization
- Smart Management: OTA updates, SMS/APP configuration, and real-time status analysis
| Hardware Platform | LTE Cat. 1 Module |
| Working Voltage | 9-90V Wide Voltage |
| Working Current | 25mA@12V |
| Positioning | Satellite + Base Station (<10m error) |
| GPS Antenna | GPS/BD Dual-mode Ceramic |
| Network Standard | LTE-TDD:B34/38/39/40/41, FDD:B1/3/5/8 |
| Hot/Cold Start | 2s / 8s |
| Battery | 55mAh/3.7V Industrial Li-Polymer |
| Weight | 28g (Device) / 74g (Total) |
| Working Temp | -25℃ ~ +75℃ |
In The Box
1x C08L Tracker, 1x Mounting Bracket, 1x User Guide
